Description
| MV095-J – Mast Lift |
| Features |
| Standard Equipment |
| Proportional Controls |
| Automatic Pothole Protection |
| Self-lock Gate On Platform |
| Drivable At Full Height |
| Charger Protection |
| Non Marking Tyre |
| 2WD |
| Automatic Brake System |
| Emergency Lowering System |
| Flashing Beacon |
| Emergency Stop Button |
| Cylinder Holding Valve |
| Onboard Diagnostic System |
| Tilt Sensor With Alarm |
| 345°Turret Rotation |
| All Motion Alarm |
| Horn |
| Hour Meter |
| Swing Out Components Cover |
| MV095-J – Mast Lift | ||
| Size | Metric | British |
| Max. Working Height | 11.20m | 36ft 9in |
| Max. Platform Height | 9.20m | 30ft 2in |
| Max. Horizontal Reach | 3.00m | 9ft 10in |
| Up and Over Height | 7.89m | 25ft 11in |
| Overall Length | 2.53m | 8ft 4in |
| Overall Width | 1.00m | 3ft 3in |
| Overall Height | 1.99m | 6ft 6in |
| Platform Size(Length×Width) | 0.62m×0.87m | 2ft 1in×2ft 10in |
| Ground Clearance(Stowed) | 0.07m | 3in |
| Ground Clearance(Raised) | 0.019m | 1in |
| Wheelbase | 1.22m | 4ft |
| TurningRadius(Inside/Outside) | 0.23/1.65m | 9in/5ft 5in |
| Tyres | Φ381×127mm | 1ft 3in×5in |
| MV095-J – Mast Lift | ||
| Performance | Metric | British |
| SWL | 200kg | 440lb |
| Max. Occupants | 2 | 2 |
| Gradeability | 25% | 25% |
| Max. Working Slope | 2.5° | 2.5° |
| Turret Rotation | 345° | 345° |
| Jib Movement | +70°/-60° | +70°/-60° |
| Travel Speed(Stowed) | 4.5km/h | 4.5km/h |
| Travel Speed(Raised) | 0.5km/h | 0.5km/h |
| Up/Down Speed | 42/38sec | 42/38sec |
| MV095-J – Mast Lift | ||
| Weight & Power | Metric | British |
| Weight | 2950kg | 6503lb |
| Battery | 24V/240Ah | 24V/240Ah |
| Charger | 24V/30A | 24V/30A |
| Driving Motor | 24V/1.5kW | 24V/1.5kW |
| Lifting Motor | 24V/3kW | 24V/3kW |
